LKS0907

LK 510 MultiSafe

LK 510 MultiSafe is a safety relief valve for tap water installations, as well as heating systems with closed boiler system with a power of max.50 kW. The valve must not be used for steam. The outlet is fitted ...

Read more

LKS0907

LK 510 MultiSafe

  • Variants
  • Detailed Information
  • Documentation

Variants

Article Dim. Opening pressure Discharge capacity Packaging Environment Item List
500 53 20 ¾" / ¾" 0,15 MPa 35 l/min
500 53 21 ¾" / ¾" 0,25 MPa 38 l/min
500 53 05 ¾" / 22 mm 0,15 MPa 35 l/min
500 53 04 0,20 MPa 35 l/min
500 53 06 0,25 MPa 38 l/min
500 53 07 0,30 MPa 40 l/min

500 53 20

Dim. ¾" / ¾"
Opening pressure 0,15 MPa
Discharge capacity 35 l/min
Packaging
Packaging
Item list

500 53 21

Dim. ¾" / ¾"
Opening pressure 0,25 MPa
Discharge capacity 38 l/min
Packaging
Packaging
Item list

500 53 05

Dim. ¾" / 22 mm
Opening pressure 0,15 MPa
Discharge capacity 35 l/min
Packaging
Packaging
Item list

500 53 04

Dim.
Opening pressure 0,20 MPa
Discharge capacity 35 l/min
Packaging
Packaging
Item list

500 53 06

Dim.
Opening pressure 0,25 MPa
Discharge capacity 38 l/min
Packaging
Packaging
Item list

500 53 07

Dim.
Opening pressure 0,30 MPa
Discharge capacity 40 l/min
Packaging
Packaging
Item list

Detailed Information

Description

LK 510 MultiSafe is a safety relief valve for tap water installations, as well as heating systems with closed boiler system with a power of max.50 kW. The valve must not be used for steam. The outlet is fitted with compression fitting for simple installation of a discharge pipe.The safety relief valve can be installed horizontally or vertically, i.e. with the valve knob facing outwards or upwards. In horizontal installations the outlet must be positioned so that a water pocket cannot be formed.
The thread has to be sealed in the usual manner.

It is easier to fit the compression fitting if a lubricant is applied to the thread and bevel. Tighten first by hand and then with a box spanner. Number of turns to be tightened with a spanner: See the separate datasheet for compression fittings. Soft pipes are to be fitted with a support sleeve.
The safety relief valve requires no maintenance. The opening function should, however, be checked 2-3 times a year.:

Turn the knob counterclockwise by hand, until water flows out. Let the water flush through for a moment. Then turn the knob until a click is heard, about ¼ turn, and the valve returns to closed position.

The safety relief valve may open after a large discharge from the water heater. This is a normal function since the pressure relief level in the water heater can be reached due to the increased volume of the water when heated.

Documentation

Product sheet

LK 510 MultiSafe
